Sliding insulated system SMARTIA S350
SMARTIA S350 is a modern & flexible insulated sliding system with a modern flat design. It is ideal for refurbishments or renovations thanks to its construction easiness.
Advantages
Maximum visibility and natural light, with only 25 mm width at the interlocking profile
Easy access with a low threshold, ideal for renovations (version SMARTIA S350 LT)
Significant energy savings, thanks to the system's energy efficiency
Wide variety of typologies, compatible with various mechanisms
High quality with certified performance
Technical Characteristics
SASH DEPTH35 mm
MINIMUM VISIBLE ALUMINIUM FACE HEIGHT101 mm
MINIMUM VISIBLE ALUMINIUM FACE WIDTH AT THE CENTRAL VERTICAL COLUMN (INTERLOCKING PROFILE)
GLAZING TYPEDouble
MAXIMUM GLAZING THICKNESS up to 28 mm
MECHANISM Perimetrical locking mechanism
SEALING METHODContinuous perimetrical tri fin in two levels brush
TYPE OF THERMAL INSULATIONPolyamides 24 mm, Thermoplastic
All available typologies
Double horizontal sliding sash
Triple horizontal sliding sash
Four horizontal sliding sashes with meeting stile
Double horizontal parallel sliding window with fly-screen
quadruple horizontal parallel sliding with meeting stile & fly-screen
Double horizontal parallel sliding window with fly-screen & rolling shutter
Horizontal sliding pocket sash with shutter
Single horizontal sliding pocket sash with fly-screen and shutter
Double pocket horizontal sliding window with fly-screen & shutter
Single horizontal sliding pocket sash with fly-screen and rolling shutter
Double horizontal parallel sliding window with fixed fanlight
Double sliding sash with fixed lightMedia Gallery
+ 6
Sections
